[Product Description]
● Chuck: Keyless chuck system (Φ1.5 to Φ13mm).
● Drilling capacity (with 18V 5Ah battery): (High mode) Hole saw SPC (Φ21×1.6mm) approximately 45 holes, (High mode) Woodwork and Japanese cedar (Φ15×120mm) approximately 260 holes, (High mode) Woodwork and Japanese cedar (Φ21×120mm) approximately 160 holes, (High mode) Woodying core drill (Φ65×cladding material 16mm + plywood 12mm) approximately 45 holes.
● Compatible with DUAL 14.4V/18V.
● Body only.
● Meets dust and water resistance IP56 standards.
● Equipped with +BRAIN and vector control technology, utilizing a high-performance microcontroller and our proprietary algorithms to constantly sense operation, providing real-time motor speed and power control.
● The smallest and lightest in our history, 160mm length and 1.85kg weight, 29mm shorter and 150g lighter than EZ74A3LJ2G.
● Faster drilling, strong for continuous work. Work speed increased by approximately 10%, work volume by approximately 15%, and continuous work volume by approximately 15% (compared to EZ74A3).
● Four-step adjustable maximum rotation speed, reducing wear on metal hole saw blades and enabling more delicate drilling.
● Evolved tap mode with two modes: for chip breaking and tap finishing.
● Electronic clutch allows torque setting according to work and material.
● Equipped with a new large-capacity storage case. Stores large tools and features stacking grooves for stability during transport.
● Side storage space for spare bits near the battery attachment, capable of holding two 65mm bits.
● Comes with a one-year warranty for peace of mind.
● Overall size: Length 160mm × Height 198mm × Width 66mm. Weight: 1.13kg.
● Max tightening torque (elastic body tightening torque) (with 18V): High speed: approximately 12N·m, Low speed: approximately 31N·m, Rigid body tightening torque (low speed): approximately 50N·m.
● Rotation speed (with 18V): High speed: 70–1,800 rpm, Low speed: 20–530 rpm.
● Clutch operation torque (with 18V): High speed: approximately 3–8N·m, Low speed: approximately 3–18N·m.
● LED light: activated with switch.
