15A Electric Bike Controller Kit Waterproof LCD8H Meter Bicycle Conversion Kit with 1 to 2 Wire for 250W 350W Motor

Feature: 1. [Complete Kit] Professional bicycle lithium battery modification controller kit includes 15A controller, LCD8H instrument, 130X finger dial, 8C power assist sensor and one to two connection wire. 2. [Good Heat Dissipation] Bicycle modification controller housing is made of high quality metal with grooves design, which has good heat dissipation, protects the internal circuit and avoids thermal overload. 3. [Waterproof Meter] Electric bike modified meter is made of high quality ABS material, with good toughness and waterproof performance, providing better protection, light and durable. 4. [Multi Function Meter] Electric bike conversion kit with LCD8H display meter with multiple functions to display battery level, backlight, brake, temperature, travel time, speed, etc, allowing you to easily view. 5. [Application] Electric bicycle 15A controller kit, suitable for 250W, 350W brushless motor. Mainly used for DIY electric scooters, folding bikes, etc. Improve riding fun, suitable for cyclists who like a challenge.

Specification: Item Type: Electric Bike Controller Kit Material: Aluminum Alloy + ABS Plastic Controller Box: Approx. 82 x 53 x 31mm / 3.2 x 2.1 x 1.2in Meter: Approx. 109 x 67mm / 4.2 x 2.6in Controller Rated Voltage: DC 36V/48V Controller Rated Current: 7A Controller Maximum Current: 15±1A Controller Speed Setting: 1-4.2V Controller Brake Input: Low Level Controller Low Voltage Protection: DC 30/40±0.5V Applicable Brushless Motor Power: 250W, 350W Connector Type: Full Waterproof Connector 1 to 2 Wire Description: One end is connected to the controller, the other end is connected to the meter and dial Controller Wire Definition: 1. Red, black single wire: Power wire 2. Black single large wire (9pin): Motor wire 3. Black single wire (9pin): 1 to 2 wires 4. Black single wire (3pin): PAS power sensor wire LCD8H Meter Function Description: Up Button, Switch Button, Down Button, PAS Mark, Battery Capacity Indication, Power Display, Running Mark, One Way Time, Total Travel Time, Battery Voltage, Brake Display, 6km/h Thrust Assist, Riding Speed (Metric), Maximum Speed, Average Speed, Distance Traveled, Total Distance, Backlight and Headlights, Ambient Celsius, Ambient Fahrenheit.

How to Use: Controller: The wire color definition interface on the controller can be connected to the socket of the accessory to realize the function. For the specific operation, please refer to the wiring diagram and manual.

Package List: 1 x Controller 1 x Meter 1 xMeter Mounting Bracket 4 x Meter Mounting Bracket Gasket 2 x Meter Mounting Bracket Screws 1 x Meter Manual 1 x Throttle Finger Dial 1 x Power Assist Sensor 1 x Controller Wiring Manual 1 x One to Two Connecting Wire

Note: 1. Retrofit kits must be fully waterproof kits.2. Manual measurement, please allow some errors.
